NVX XSBI200 Dual Sensing Smart Relay Battery Isolator – 200A Microprocessor-Controlled
- £82.38
- £82.38
- Unit price
- per
Couldn't load pickup availability
Free UK Delivery on All Orders
Free Returns
Description
xOverview
The NVX XSBI200 Dual Sensing Smart Relay Battery Isolator is engineered to intelligently manage a secondary battery, commonly dedicated to a vehicle’s audio system or auxiliary loads. With microprocessor-controlled logic and dual sensing, it helps you organize power delivery while keeping the primary starting battery ready for action. This design emphasizes practical power management without implying guarantees, offering potential improvements in system reliability and energy handling for real-world use.
Key benefits
- Isolates a secondary battery to protect the primary starting battery, reducing the risk of unexpected power drain.
- Delivers power to the secondary battery without introducing a voltage drop, unlike some traditional isolators.
- Supports 200 Amps of continuous power at 12 V, with up to 300 Amps surge capacity for brief peak demands.
- Low idle draw and switching power range of 10–16 VDC help conserve battery life while the system is active.
- Compact dimensions (2-3/8" W x 2-3/8" D x 3-3/4" H) enable installation in tight spaces under dashboards or in compact enclosures.
Real-world use cases
Think of a tuned car audio setup powered by a separate battery or a marine rig where accessories run independently from the engine start battery. The XSBI200 provides a practical way to manage two battery banks without common interference between critical and non-critical loads. Its dual sensing capability reacts to voltage changes with dependable timing, offering a balanced approach to power distribution that suits daily drives, weekend adventures, and hobby installations.
What to expect in your install
Designed for straightforward wiring, this module is built to perform in typical automotive environments. Its compact form supports flexible mounting options, while its microprocessor-driven controls bring consistent performance across varying electrical demands. Use it to create a dedicated power path for a stereo or auxiliary system, with the assurance of a clean separation from starting power.
Specifications at a glance
- Continuous power: 200 A at 12 V
- Surge power: 300 A
- Switching power: 10–16 VDC
- Current draw when ON: < 1 A
- Dimensions: 2-3/8" W x 2-3/8" D x 3-3/4" H
- Brand: NVX
FAQ
Q: What is the NVX XSBI200 best used for?
A: Isolates a second battery for a dedicated stereo or accessory circuit, reducing risk to the starting battery while avoiding voltage drop.
Q: What power handling does the XSBI200 offer?
A: 200 A continuous at 12 V with 300 A surge, plus switching power of 10–16 VDC and low on-state draw.
